Technical Specifications
- Manufacturer: PT Global
- Model Series: PT4000 (S-Type)
- Part Number (SKU): 40P1000T000XXX
- Rated Capacity: 1000 lb (Pounds)
- Measurement Modes: Tension and Compression (Bi-directional)
- Material: Nickel-plated alloy tool steel
- Rated Output (Sensitivity): 3.00 mV/V ± 0.25%
- Input Resistance: 385 Ω ± 15 Ω
- Output Resistance: 350 Ω ± 3 Ω
- Insulation Resistance: ≥ 5000 MΩ
- IP Rating: IP67 (Environmental protection)
- Thread Type: Imperial (UNF thread)
- Cable Configuration: 4-core polyurethane jacketed cable with braided shield
- Safe Overload: 150% of rated capacity
- Ultimate Overload: 300% of rated capacity
