CHECK VALVE SANDWICH PLATE Z2S6-1-6X/V/62
Industrial hydraulic valve in a high-performance range. Reliable blocking of the oil flow according to the hydraulic symbol
- Direct actuated
- Leakage-free blocking in channel A and B
- Cracking pressure 1.5 bar
Specifications
- Size 6
- Component series 6X
- Maximum operating pressure 315 bar
- Maximum flow 60 l/min
Product attributes
|
Connection diagram |
ISO 4401-03-02-0-05 |
|
Product family |
Z2S6 |
|
Operating pressure, max. [bar] |
350 |
|
Max. flow [l/min] |
80 |
|
Spool symbol |
A1 → A2, B1 → B2 |
|
Type of connection |
Sandwich plate |
|
Size |
6 |
|
Type of actuation |
with mechanical actuation |
|
Number of ports |
4 |
|
Number of switching positions |
2 |
|
Hydraulic fluid |
HL,HLP,HLPD,HVLP,HVLPD,HETG,HEES,HEPG,HFDU,HFDR |
|
Seals |
FKM |
