Product charateristics
Technical Specifications
| Switching function | Two-way switch |
|---|---|
| Number of contacts as normally open contact | 0 |
| Number of contacts as normally closed contact | 0 |
| Number of contacts as change-over contact | 2 |
| Number of poles | 4 |
| Rated current | 32 A |
| Rated voltage | 400 V |
| Min. rated voltage | 380 V |
| Short-circuit breaking capacity (Icw) | 0.384 kA |
| Voltage type | AC |
| With complemantary luminous signal | No |
| Colour calotte | Other |
| Lamp type | Other |
| Lamp socket | Other |
Specifications
| Width in number of modular spacings | 2 |
|---|---|
| Built-in depth | 44 mm |
| Degree of protection (IP) | IP20 |
| Width | 35.6 mm |
| Height | 94 mm |
| Depth | 76 mm |
| Operating / setting temperature | -5-40 °C |
| Storage temperature | -10-70 °C |
| Terminal marking indication | Yes |
| Connection type | Screwed terminal |
| Terminals capacity | 1.5-6 mm² |
| Label space/information surface | Yes |
| Mounting method | DIN rail |
