| Brand | Twin Filter |
| Industry | Oil and Gas |
| Function | Absorption |
| Filter Construction | Packed Media |
| Media | Organoclay |
| Materials of Construction | Molded Polypropylene |
| Outside Diameter | 2.5 inch, 64.0 mm |
| Inside Diameter | 1.1 inch, 28.0 mm |
| Connection Size | Type 222 (code 3) |
| Weight | 1.6 lb, 0.7 kg |
| Maximum Operating Temperature | 140.0 °F, 60.0 °C |
| Maximum Flow Rate | 6.29 Bbl/hr, 1.0 m3/hour per 39 inch Cartridge |
| pH Range | 1-9 |
| Maximum Pressure Differential | 36.3 psi, 2.5 bar |
| Flow Direction | Radial Flow |
| Length | 40 inch (1005 mm) |
Benefits:
- 99% removal of oils in a single pass.
- Cartridge blocks after saturation and no hydrocarbon bypass is possible.
- The absorption capacity can be up to 4 times its own weight.
- No direct contact with saturated media during handling.
- High flow rates.
- Specially designed for the offshore industry.
- Reliable and simple solution.
- Easy handling and operation.
- Fit into existing cartridge filter units.
- Manufacturing process eliminates voids in media and thus bypass issues.
Applications:
- Mud pit cleaning
- Produced water
- Displacement clean-up
- Acid flow back
- Completion fluids
- Pipeline, system purge & hydro test discharges
- Ballast and bilge water
- Run-off water
