| Body Material | Steel |
| Product Style | Union |
| Connection 2 Size | 12 mm (O.D.) |
| Connection 1 Size | 12 mm (O.D.) |
| Accessories Included | Pre-assembled with Nut and EO-PSR Cutting Ring |
| Connection 3 Size | 12 mm (O.D.) |
| Brand | Ermeto |
| Shape | Tee |
| Division | High Pressure Connectors Europe Division |
| Connection 1 Type | Male 24° Cone |
| Technology | Fluid & Gas Handling |
| Industry | Agriculture, Automotive, Construction, Industrial Manufacturing Equipment, Marine, Material Handling, Transportation |
| Connection 2 Type | Male 24° Cone |
| Connection 3 Type | Male 24° Cone |
| Application | Chemical Transfer, Fuel Transfer, Hydraulics, Mobile Equipment, Oilfield, Packaging |
| Product Type | Hydraulic DIN Fittings |
| Shape | Union, Union Tee |
| Product Series | EO Heavy |
| Configuration | Tube to Tube |
| Maximum Operating Pressure | 630 bar |
| Connection 1 Type | Male, 24° Cone |
| Connection 1 Size | 12 mm Tube O.D. |
| Connection 2 Type | Male, 24° Cone |
| Connection 2 Size | 12 mm Tube O.D. |
| Connection 3 Type | Male, 24° Cone |
| Connection 3 Size | 12 mm Tube O.D. |
| Specifications Met | DIN, ISO 8434 |
| For Fluid Type | Hydraulic Fluids, Chemicals, Fuels, Gases, Steam |
| Accessories Included | Pre-assembled with Nut and EO-PSR Cutting Ring |
| Body Material | Steel |
| Seal Type | Sealing Edge |
| Seal Material | n/a |
| Maximum Ambient Temperature | 300 °C, 572 °F |
| Minimum Ambient Temperature | -40 °C, -40 °F |
| Maximum Fluid Temperature | 300 °C, 572 °F |
| Minimum Fluid Temperature | -40 °C, -40 °F |
