Kinetrol Rotary Pneumatic Actuator Specification
1. General Requirements
- Technology: Single-vane rotary engineering.
- Design: Quarter-turn 90° rotation.
- Mechanism: Direct torque transmission.
- Action Types: Double-acting or spring-return.
-
Backlash: Zero backlash output shaft.
2. Materials & Construction
- Casing: Die-cast aluminum alloy.
- Finish: Epoxy-based yellow stove enamel.
- Vane & Shaft: Integral zinc-plated steel.
- Vane & Shaft Option: One-piece stainless steel.
-
Seals: Polyurethane double-opposed lip seals.
3. Operational Performance
- Torque Range: 0.1 Nm to 40,000 Nm.
- Working Pressure: 1.4 bar to 7.0 bar.
- Maximum Pressure: 7.0 bar (100 psi).
- Standard Temperature: -40°C to +80°C.
- High Temperature: Up to +100°C with fluorocarbon seals.
-
Low Temperature: Down to -55°C with silicone seals.
4. Controls & Ancillaries
- Interface: Modular direct-mount design.
- Limit Switches: Direct-mounted box options.
- Positioners: Pneumatic or electro-pneumatic.
- Solenoids: Direct NAMUR interface.
-
Manual Override: Declutchable gear operators.
5. Compliance & Certification
- Hazardous Areas: ATEX certified Category 1.
- Safety Integrity: SIL 3 rated.
- Ingress Protection: IP66 / NEMA 4X rated.
- Quality Assurance: ISO 9001 standard.
