Power Supply
- Rated Voltage: 380V AC to 415V AC
- Operating Limits: -15% to +10% of rated voltage
- Consumption: 10 VA maximum
- Frequency: 50 Hz or 60 Hz
Current Input (CT)
- Rated Current (In): 5A
- Operating Range: 0.05A to 6.5A
- Rated Burden: Under 0.5 VA at 5A
Control Ranges
- Target Power Factor: 0.85 Lagging to 0.95 Leading
- C/K Value: 0.03 to 1.20 (or automatic setup)
- Switching Delay Time: 5 seconds to 600 seconds
- Reconnection Delay Time: 5 seconds to 600 seconds
- Switching Program: Automatic, Linear, Rotational, or Manual
Outputs
- Number of Steps: 12 steps
- Contact Type: Normally Open (NO) dry contacts
- Contact Rating: 5A, 250V AC (Resistive load)
- Max Total Current: 12A continuous
Mechanical and Environmental
- Mounting: Panel flush mounting
- Front Panel Dimension: 144 mm x 144 mm
- Panel Cutout Dimension: 138 mm x 138 mm
- Depth: 90 mm
- Approximate Weight: 1.2 kg
- Operating Temperature: -10°C to +55°C
- Enclosure Rating: IP54 at the front panel
